Mcelty® PDX: Highly Flexible Accumulation Pallet Conveyor System
Optimize your manufacturing process with Mcelty® PDX, a modular conveyor system designed for businesses and industries of all sizes. Offering flexibility and innovation, it provides tailored solutions to meet specific requirements.
Key Features
Efficient Transport
- A single drive motor can transport workpieces up to 10 meters.
- For distances beyond 10 meters, coupled conveyors enable seamless extension to unlimited lengths.
Customizable Modular Combinations
- Modules can be grouped to handle large and heavy workpieces.
- Transport carrier dimensions (length, width) and quantities can be flexibly configured to meet specific needs.
Smooth and Continuous Operation
- Utilizes friction clutches or magnetic clutches to ensure consistent and reliable transport operations.
Advanced Layout Options
- Coupled Conveyors: Seamlessly extend transport distances.
- Transfer Vehicles: Efficiently connect material flow between workstations.
- Lifting Devices: Bridge height differences between production zones.
- Rotating Units: Enable multi-directional workpiece positioning.
- Storage Modules: Increase buffer capacity for system scalability.
Mcelty® PDX Product Variants
Standard Configuration
- Sturdy and durable, ideal for general applications.
45° / 60° / 90° Turning Configurations
- Increased Storage: Pallets buffered on both sides to enhance storage capacity.
- Ergonomic Design: Facilitates operator-friendly loading/unloading.
- Flexible Positioning: Supports horizontal or upright workpiece transport.
- Versatile Loading: Front or side loading/unloading options.
- Adjustable Layout: Separation units and stop points can be customized as needed.
Innovative Storage and Transport Solutions
Rotating Tower Storage
- Enables multi-level component storage.
- Parts are supplied to robots via rotating drives for loading/unloading.
- Optional configurations include cooling storage units.
Inclined Lifts
- Smoothly connect production zones at different heights.
- Supports transport of workpieces in horizontal or vertical positions.
Integration and Safety
- Fully compatible with the originally designed steel structural system.
- Includes integrated safety components to ensure operator protection.
Advantages
- Flexible Customization: Seamlessly integrates into various factory layouts.
- Enhanced Ergonomics: Improves operator comfort and efficiency.
- Technological Innovation: Advanced modular designs ensure a competitive edge.
Mcelty® PDX delivers exceptional flexibility, reliability, and efficiency, making it the ideal solution for optimizing modern manufacturing workflows.
